- DIY Compatible: Designed for DIY enthusiasts, this miniature 2‑phase 4‑wire stepper motor slide table is for small slider projects, measurement equipment, and printers.
- All-Metal Planetary Gearbox: Equipped with an all-metal structure, the planetary gearbox reducer ensures smooth , enhancing the motor's performance.
- Precise Diagonal Movement: Drive precise diagonal lines with the metal slider moving up and down effortlessly. The sturdy metal bracket provides a stable foundation for accurate movements.
- Stable Performance: Powered by a 2‑phase 4‑wire motor, this stepper motor slide table operates with a drive voltage of 4-9V/100-500mA. It offers professional performance with exceptional stability.
- Premium Stainless Steel Construction: Crafted from premium stainless steel, this slide table is rugged, -resistant, and built to last, guaranteeing a long lifespan for your projects.
1. Suitable for DIY small slider/project/measurement equipment printer.
2. Miniature 2‑phase 4‑wire stepper motor with planetary gearbox. The planetary gearbox reducer adopts an all‑metal structure.
3. Drive precise diagonal lines to move the metal slider up and down. The bracket is basically made of a metal structure.
4. 2‑phase 4‑wire motor, 4‑9V/100‑500mA drive voltage, it has stable and professional performance.
5. Made of premium stainless steel material, rugged, anti‑corrsion , long lifespan.
Spec:
Condition: 100% Brand New
Item Type: Stepper Motor Screw
Material: Stainless Steel
Color: As picture shown
Motor Type: 2-Phase 4-Wire System
Drive Voltage: 4-9V/100-500mA (the higher the voltage, the greater the force, the greater the heat)
Screw Length: Approx. 90mm/3.5in
Slider Stroke: Approx. 80mm/3.1in
Motor Diameter: Approx. 15mm/0.6in
Screw Diameter: Approx. 3mm/0.1in
Screw Thread Pitch: Approx. 0.5mm/0.02in (0.025mm in one step, if smaller, you can use subdivision drive)
Step Angle: 18°
Phase Resistant: 15.5 Ohms
Blue A Black A- Red B Yellow B-
packing list:
1 x Stepper Motor Screw
Note:
Please note that it is a stepper motor, it will not turn when it is directly connected to the power supply. It requires a stepper motor drive board and a control board.
